Lightsoft

Model Number: ULH-108XX

Ratings: IP65 F CE IK07 ETL

The innovative reflector technology of the Lightsoft bollard guarantees a high degree of efficiency and optimal visual comfort. Lightsoft has been developed to have excellent controlled downward light providing wide spacing ratios. It has three light shield accessories with different light distributions.

The Lightsoft bollard comes standard with a unique waterproof internal driver housing compartment that is situated at the top of the pole to stop water and dust from entering the electrical components. This fixture is supplied completely wired with power cord and waterproof gland from the driver enclosure to the base of the bollard ensuring quick, trouble-free installation. Custom bollard heights are available. Color temperatures include; 2700, 3000 and 4000 Kelvin.

• Die-cast aluminum housing

• Extruded aluminum column

• Pre-treated before powder coating ensuring high corrosion resistance

• Stainless steel fasteners in grade 316

• Durable silicone rubber gasket

• Clear tempered glass

• Integral control gear

• Solar panel mono-crystalline silicon high-efficiency 4x10W

• Lithium Iron Phosphate (LiFePO4 ) battery 16.5Ah 12Vdc

• Solar charger controller system 12V 10A

• Different dimming scenarios: 5 Step dimming, 2 Step dimming, Dusk to Dawn (D2D) and Custom hours

• Maximum 15 hours of operation time (100%)

• Without any sun (Autonomy), the battery would last for maximum 5 days

• Full automatic electronic protection function against short circuit, overcurrent, overload, over voltage and high temperature

• Peak Sun-Hour used in the calculations is 3 hours per day

• Remote solar charge controller can be ordered as an accessory

• Standard: Off-grid, 100% solar, not connected to the utility grid

• Utility grid connection is available upon request
